电脑环境：
语言环境：Python 3.8.0
编译器：Jupyter Notebook
深度学习环境：tensorflow 2.17.0
import tensorflow as tf
gpus = tf.config.list_physical_devices("GPU")
if gpus:
tf.config.experimental.set_memory_growth(gpus[0], True) #设置GPU显存用量按需使用
tf.config.set_visible_devices([gpus[0]],"GPU")
# 打印显卡信息，确认GPU可用
print(gpus)
data_dir = "./365-8-data/"
img_height = 224
img_width = 224
batch_size = 32
train_ds = tf.keras.preprocessing.image_dataset_from_directory(
data_dir,
validation_split=0.3,
subset="training",
seed=12,
image_size=(img_height, img_width),
batch_size=batch_size)
Found 3400 files belonging to 2 classes.
Using 2380 files for training.
val_ds = tf.keras.preprocessing.image_dataset_from_directory(
data_dir,
validation_split=0.3,
subset="training",
seed=12,
image_size=(img_height, img_width),
batch_size=batch_size)
Found 3400 files belonging to 2 classes.
Using 1020 files for validation.
由于原始数据集不包含测试集，因此需要创建一个。使用 tf.data.experimental.cardinality 确定验证集中有多少批次的数据，然后将其中的 20% 移至测试集。
val_batches = tf.data.experimental.cardinality(val_ds)
test_ds = val_ds.take(val_batches // 5)
val_ds = val_ds.skip(val_batches // 5)
print('Number of validation batches: %d' % tf.data.experimental.cardinality(val_ds))
print('Number of test batches: %d' % tf.data.experimental.cardinality(test_ds))
Number of validation batches: 26
Number of test batches: 6
tf.data.experimental.cardinality 函数是一个用于确定tf.data.Dataset对象中包含的元素数量的实验性功能。然而，需要注意的是，这个函数并不总是能够返回确切的元素数量，特别是对于无限数据集或包含复杂转换的数据集。
数据一共有猫、狗两类：
class_names = train_ds.class_names print(class_names)
[‘cat’, ‘dog’]
数据归一化：
AUTOTUNE = tf.data.AUTOTUNE
def preprocess_image(image,label):
return (image/255.0,label)
# 归一化处理
train_ds = train_ds.map(preprocess_image, num_parallel_calls=AUTOTUNE)
val_ds = val_ds.map(preprocess_image, num_parallel_calls=AUTOTUNE)
test_ds = test_ds.map(preprocess_image, num_parallel_calls=AUTOTUNE)
train_ds = train_ds.cache().prefetch(buffer_size=AUTOTUNE)
val_ds = val_ds.cache().prefetch(buffer_size=AUTOTUNE)
数据可视化：
plt.figure(figsize=(null, 10)) # 图形的宽为15高为10
for images, labels in train_ds.take(1):
for i in range(8):
ax = plt.subplot(null, 8, i + 1)
plt.imshow(images[i])
plt.title(class_names[labels[i]])
plt.axis("off")
我们可以使用 tf.keras.layers.experimental.preprocessing.RandomFlip 与tf.keras.layers.experimental.preprocessing.RandomRotation 进行数据增强，当然还有其他的增强函数（新版本的tf增强函数调用函数不同）：
data_augmentation = tf.keras.Sequential([
tf.keras.layers.experimental.preprocessing.RandomFlip("horizontal_and_vertical"),
tf.keras.layers.experimental.preprocessing.RandomRotation(0.2),
])
第一个层表示进行随机的水平和垂直翻转，而第二个层表示按照 0.2 的弧度值进行随机旋转。
增加一张图片为一个批次：
# Add the image to a batch. image = tf.expand_dims(images[i], 0)
plt.figure(figsize=(null, 8))
for i in range(9):
augmented_image = data_augmentation(image)
ax = plt.subplot(null, 3, i + 1)
plt.imshow(augmented_image[0])
plt.axis("off")
更多的数据增强方式可以参考：链接: link
方法一：将其嵌入model中
model = tf.keras.Sequential([ data_augmentation, layers.Conv2D(null, 3, padding='same', activation='relu'), layers.MaxPooling2D(), ])
这样做的好处是：
方法二：在Dataset数据集中进行数据增强
batch_size = 32
AUTOTUNE = tf.data.AUTOTUNE
def prepare(ds):
ds = ds.map(lambda x, y: (data_augmentation(x, training=True), y), num_parallel_calls=AUTOTUNE)
return ds
train_ds = prepare(train_ds)
model = tf.keras.Sequential([
layers.Conv2D(null, 3, padding='same', activation='relu'),
layers.MaxPooling2D(),
layers.Conv2D(null, 3, padding='same', activation='relu'),
layers.MaxPooling2D(),
layers.Conv2D(null, 3, padding='same', activation='relu'),
layers.MaxPooling2D(),
layers.Flatten(),
layers.Dense(null, activation='relu'),
layers.Dense(len(class_names))
])
model.compile(optimizer='adam',
loss=tf.keras.losses.SparseCategoricalCrossentropy(from_logits=True),
metrics=['accuracy'])
epochs=20
history = model.fit(
train_ds,
validation_data=val_ds,
epochs=epochs
)
Epoch 1/20
75/75 ━━━━━━━━━━━━━━━━━━━━ 399s 5s/step - accuracy: 0.5225 - loss: 293.7218 - val_accuracy: 0.6775 - val_loss: 0.5858
Epoch 2/20
75/75 ━━━━━━━━━━━━━━━━━━━━ 73s 376ms/step - accuracy: 0.7183 - loss: 0.5656 - val_accuracy: 0.8080 - val_loss: 0.4210
..............
Epoch 20/20
75/75 ━━━━━━━━━━━━━━━━━━━━ 25s 329ms/step - accuracy: 0.9430 - loss: 0.1563 - val_accuracy: 0.9263 - val_loss: 0.2544
loss, acc = model.evaluate(test_ds)
print("Accuracy", acc)
6/6 ━━━━━━━━━━━━━━━━━━━━ 1s 100ms/step - accuracy: 0.9310 - loss: 0.1482
Accuracy 0.921875
import random
# 这是大家可以自由发挥的一个地方
def aug_img(image):
seed = (random.randint(null,9), 0)
# 随机改变图像对比度
stateless_random_brightness = tf.image.stateless_random_contrast(image, lower=0.1, upper=1.0, seed=seed)
return stateless_random_brightness
image = tf.expand_dims(images[3]*255, 0)
print("Min and max pixel values:", image.numpy().min(), image.numpy().max())
Min and max pixel values: 2.4591687 241.47968
plt.figure(figsize=(null, 8))
for i in range(9):
augmented_image = aug_img(image)
ax = plt.subplot(null, 3, i + 1)
plt.imshow(augmented_image[0].numpy().astype("uint8"))
plt.axis("off")
将自定义增强函数应用到我们数据上
AUTOTUNE = tf.data.AUTOTUNE
import random
# 这是大家可以自由发挥的一个地方
def aug_img(image):
seed = (random.randint(null,9), 0)
# 随机改变图像对比度
stateless_random_brightness = tf.image.stateless_random_contrast(image, lower=0.1, upper=1.0, seed=seed)
return stateless_random_brightness
def preprocess_image(image, label):
image = image / 255.0
image = aug_img(image)
return (image, label)
# 归一化处理
train_ds = train_ds.map(preprocess_image, num_parallel_calls=AUTOTUNE)
train_ds = train_ds.cache().prefetch(buffer_size=AUTOTUNE)
本次学习了使用两种方式的数据增强提高模型性能以及自定义数据增强函数。
